Model | Dimension | Optical Power | Drive Voltage(DC V) | Wavelength | Drive Current | Beam Profile | |
ABDF653 | Ø10 x 50mm | < 2.9mW | 5 | 655nm ± 5 | < 30mA | Gaussian |  |
| AMD4060 | Ø16 x 120mm | < 60mW | 12 | 405nm ± 10 | < 150mA | Gaussian |  |
| AMD4560 | Ø16 x 120mm | < 60mW | 12 | 450nm ± 10 | < 150mA | Gaussian |  |
| AMD5240 | Ø16 x 120mm | < 40mW | 12 | 520nm ± 10 | < 200mA | Gaussian |  |
| AML6560-(Angle) | Ø16 x 120mm | < 60mW | 7 ~ 24 | 655nm ± 5 | < 120mA | Gaussian |  |
| AML6595-(Angle) | Ø16 x 120mm | < 95mW | 7 ~ 24 | 655nm ± 5 | < 130mA | Gaussian |  |
| AMLG525V-(Angle) | Ø16 x 120mm | < 40mW | 12 | 520nm ± 10 | < 200mA | Gaussian |  |
| AMLG525V-45 | Ø16 x 120mm | < 40mW | 12, 24 | 520nm ± 10 | < 200mA | Gaussian |  |
| AMLX635-(Angle) | Ø16 x 80mm | < 5mW | 12 | 635nm ± 5 | < 150mA | Gaussian |  |
| AMLX635-30 | Ø16 x 80mm | < 5mW | 12 | 635nm ± 5 | < 150mA | Gaussian |  |
| AMLX4560-(Angle) | Ø16 x 80mm | < 60mW | 7 ~ 24 | 450nm ± 5 | < 150mA | Gaussian |  |
| AMLX4560-30 | Ø16 x 80mm | < 60mW | 12 | 450nm ± 5 | < 150mA | Gaussian |  |
| AMLX5240-(Angle) | Ø16 x 80mm | < 40mW | 12 | 520nm ± 5 | < 150mA | Gaussian |  |
| AMLX6595-(Angle) | Ø16 x 82.4mm | < 95mW | 7 ~ 24 | 655nm ± 5 | < 130mA | Gaussian |  |
| ATL6515-(Angle) | Ø16 x 109.4mm | < 15mW | 7 ~ 24 | 655nm ± 5 | < 100mA | Gaussian |  |
| ATL6595-(Angle) | Ø16 x 111.3mm | < 95mW | 7 ~ 24 | 655nm ± 5 | < 130mA | Gaussian |  |
| ATLSC4560-30 | Ø16 x 209.9mm | < 60mW | 12 | 450nm ± 10 | < 150mA | Gaussian |  |
| ATLX4560-15 | Ø16 x 109.4mm | < 60mW | 12 | 450nm ± 10 | < 150mA | Gaussian |  |
| ATLX4560-30 | Ø16 x 81.9mm | < 60mW | 12 | 450nm ± 10 | < 150mA | Gaussian |  |
| ATLX6560-(Angle) | Ø16 x 81.9mm | < 60mW | 7 ~ 24 | 655nm ± 5 | < 100mA | Gaussian |  |
| ATLX6560-15 | Ø16 x 109.4mm | < 60mW | 7 ~ 24 | 660nm ±7 | < 120mA | Gaussian |  |
| ATU4560-(Angle) | Ø16 x 111.3mm | < 60mW | 7 ~ 24 | 450nm ± 5 | < 150mA | Non-Gaussian |  |
| ATUX4560-(Angle) | Ø16 x 86.8mm | < 60mW | 7 ~ 24 | 450nm ± 5 | < 150mA | Non-Gaussian |  |
| ATUX4560-60 | Ø16 x 86.8mm | < 60mW | 5 | 450nm ± 5 | < 150mA | Non-Gaussian |  |
