Line Scan Strobe Lighting Module

Line Scan Strobe Lighting

It is possible to capture three different lighting images with a single shot.

(*Coaxial lighting: Black spots / Scratch lighting: Scratches / Low-angle lighting: Cracks)

Even with high-speed inspections of up to 100,000 times per second, accurate image results can be obtained.

■ Approximately 20% increase in light intensity compared to constant voltage

■ High-speed multi-strobing possible with line scan optics ( 100kHz )

■ High-speed strobing possible with TDI line scan optics ( 300kHz )

Strengths of the Product

Features of Product

One shot → Three lighting effects

  • Images can be captured without mixing for each lighting type
  • Even when operating at high speed, there is no change in the image sequence

Capable of 100,000 inspections per second

  • Even with high-speed inspections of up to 100,000 times per second, accurate image results can be extracted
  • The trigger distributor (ALT-TDS-100) helps enable high-speed shooting

Compact overall process

  • Cost and time savings
